| Model # | P31.25 | P50 | P55 | P62.5 | P83.3 | P100 |
| Dot size | Φ19 | Φ19 | Φ19 | Φ19 | Φ19 | Φ19 |
| Lamp type | SMD3535 | SMD3535 | SMD3535 | SMD3535 | SMD3535 | SMD3535 |
| Viewing angle | 120° | 120° | 120° | 120° | 120° | 120° |
| Configuration | 6RGB | 6RGB | 6RGB | 6RGB | 6RGB | 6RGB |
| Pixel pitch | 31.25 | 50 | 55 | 62.5 | 83.3 | 100 |
| Physical density | 1,024 dots/m² | 400 dots/m² | 324 dots/m² | 256 dots/m² | 144 dots/m² | 100 dots/m² |
| Grey level | 12BIT | 12BIT | 12BIT | 12BIT | 12BIT | 12BIT |
| Brightness | 12,000cd/m² | 6,000cd/m² | 5,500cd/m² | 3,800cd/m² | 2,100cd/m² | 1,500cd/m² |
| Transparency rate | 68% | 72% | 73% | 75% | 85% | 90% |
| Video frame rate | 60FPS | 60FPS | 60FPS | 60FPS | 60FPS | 60FPS |
| Refresh rate | 4,000Hz | 4,000Hz | 4,000Hz | 4.000Hz | 4,000Hz | 4,000HZ |
| In-put voltage | DC24V | DC24V | DC24V | DC24V | DC24V | DC24V |
| Max.Power | 1,152W/m² | 576W/m² | 466W/m² | 368W/m² | 208W/m² | 144W/m² |
| Weight | 8.5kg/m² | 4.5kg/m² | 4.5kg/m² | 3.5kg/m² | 2.5kg/m² | 1.4kg/m² |
| Waterproof grade | IP66 | IP66 | IP66 | IP66 | IP66 | IP66 |
| Fireproof grade | V0 | V0 | V0 | V0 | V0 | V0 |
| Connecting pixels | 380 pixels | 320 pixels | 320 pixels | 260 pixels | 220 pixels | 180 pixels |
| Connecting length | 6m | 8m | 8m | 12m | 16m | 20m |
