| Item | P2 |
| Pixel pitch | 2mm |
| Module size | 320*160mm |
| Module resolution | 160x80 |
| Physical density | 250000 dots/m² |
| LED type | SMD1515 |
| Cabinet size | 640*480*59mm |
| Cabinet resolution | 320*240 |
| Cabinet weight | 8kg |
| Cabinet material | Die casting aluminum |
| Maintenance way | Front |
| Best viewing distance | ≥2m |
| Best viewing angle | H:160°;V:160° |
| Driving method (Constant Current) | 1/40 Scan |
| Video frame rate | ≥60 Hz |
| Refresh rate | 1920-3840Hz |
| Brightness | ≥800nits |
| Grey level | 12-16bit |
| Waterproof grade | IP43 |
| Average power consumption | 290W |
| Life time | >100,000Hours |
| The rate | <0.0002 |
